Liftroller Stacker high lift pallet jack
The Liftroller Stacker is a semi-electric high lift pallet jack built for construction sites. It lifts 1,000 kg and raises the forks from 90 mm to 1,300 mm on power, and its mast is low enough to be wheeled through a window opening on a Liftroller Wall where the building has no lift.
1 / 6Talk to the team
Get pricing on the Liftroller Stacker
Tell us the floor levels, the openings you have and what you need to move. We'll come back with the right setup and what it costs.
A real reply, usually same day
Weekdays, from the team in Sydney. Not an autoresponder.
We'll tell you if it's the wrong fit
If another machine in the range suits your access better, we'll say so.
Under a minute to fill
Name, email and a number so we can call you back. Everything else is optional.
What the Liftroller Stacker does
A pallet jack that lifts properly. The forks start at 90 mm so they go under a standard pallet, and they raise on power to 1,300 mm, which is high enough to put a pack onto trestles at working height rather than leaving it on the floor.
The mast is deliberately short. That is what lets it be wheeled through a window opening on the Liftroller Wall, which is the answer when a building has no lift and no other way of getting a machine onto an upper floor.
It also loads big bags. Fill them with strip-out waste and offcuts, lift them onto the Wall, and the same crane truck that delivered the materials takes the waste away on the return trip. That keeps bins off the ground where rigging space is tight.
How it works on site
- 1
Get it to the floor
Wheel it through the opening on a Liftroller Wall, or crane it in. The low mast is what makes the first option possible.
- 2
Pick the pack up
Forks down to 90 mm slide under a standard pallet. Raise on power, no pumping.
- 3
Move it to the work face
Walk-behind, so it fits where a ride-on will not.
- 4
Set it down at height
Lift to 1,300 mm and place the pack on trestles so the trade works off it standing up.
What it lifts
Standard pallets, and anything you need lifted from floor level to working height inside the building.
- Palletised plasterboard and lining
- Tile, stone and heavy boxed goods
- Big bags of offcuts and strip-out waste
- Packs that need placing on trestles rather than the slab
Technical specifications
Every figure below was verified against the manufacturer's Australian specification sheets in August 2026.
| Specification | Value |
|---|---|
| Height including handle | 1084 mm |
| Length including handle | 1690 mm |
| Forks width | 560 mm |
| Total width | 680 mm |
| Minimum height tower | 1040 mm |
| Maximum height tower | 1710 mm |
| Minimum height forks | 90 mm |
| Maximum height forks | 1300 mm |
| Charging power | 110/230 V |
| Tare weight (with forks) | 290 kg |
| Max. weight load (WLL) | 1000 kg |
Key features
- Lifts up to 1,000kg
- Electric raise and lower, forks from 90 to 1,300mm
- Low mast fits through a window opening with the Liftroller Wall
- Loads big bags for craning waste off site
- Works with both the Liftroller Wall and Liftroller Floor
- 110/230V charging
Got a question about your site?
Openings, floor levels, load weights: send us the details and we'll tell you straight whether the Liftroller Stacker is the right call.
Where it is used
Buildings with no lift
The low mast means it can come in through the window with the Liftroller Wall, which is often the only way to get a machine upstairs.
Loading waste out
Lift big bags of offcuts onto the Wall for craning off, so waste leaves on the truck that brought the materials in.
Placing packs on trestles
1,300 mm of lift puts material at working height instead of on the slab.
Standard pallets
560 mm forks and a 90 mm lowered height suit the pallets material actually arrives on.
How it differs from a warehouse stacker
The Liftroller Stacker looks like a walkie stacker and lifts like one. What it is built for is different, and the mast height is why.
This page
Liftroller Stacker
Typical warehouse walkie stacker
| Attribute | Liftroller Stacker | Typical warehouse walkie stacker |
|---|---|---|
| Working load | 1,000 kg | Often 1,000 to 1,600 kg |
| Fork lift height | 90 to 1,300 mm | Typically higher |
| Mast height | Deliberately low | Tall |
| Fits through a window opening | Yes | No |
| Reaches floors with no goods lift | Yes | No |
| Loads big bags onto a landing platform | Yes | No |
| Own weight | 290 kg with forks | Heavier |
| Built for site conditions | Yes | No |
Choose Liftroller Stacker when
Buildings under construction, especially ones with no working goods lift.
Choose Typical warehouse walkie stacker when
A flat warehouse floor, a loading dock, and a lift if you need another level.
The warehouse column describes general characteristics of that class of machine, not one named product. Check the specification of whatever you are comparing against.
Want Liftroller Stacker pricing for your site?
Leave your details and we'll call you back with availability and what it costs for your job.
Working out whether it pays
The Stacker's case is usually access rather than raw hours: it can get to floors other machines cannot.
Labour hours on material handling
Count the people and the hours currently spent carrying, and what those hours are worth on your rates. This is usually the biggest line by a distance.
Crane and hoist time
Every lift to ground level that then has to be moved again is a lift you paid for twice. Landing on the floor removes the second handling.
The goods lift
If materials are going up in the lift, other trades are waiting for it. Freeing the lift has a programme cost attached that rarely gets counted.
Rigging and ground space
External hoists and scaffold bays need somewhere to stand and something to tie to. On a tight site that space has a real cost, or does not exist at all.
Damage and rework
Carried materials get dropped, scuffed and cornered. Sheets rolling on a level bed do not.
Injury and lost time
Manual handling is one of the largest causes of lost-time injury in Australian construction. Fewer carried loads is fewer chances for a back injury on your job.
If your building has no goods lift, the alternative is carrying, and that comparison is rarely close. Send us the building and we will tell you if it can get where you need it.
Common questions
It is a semi-electric high lift pallet jack for construction sites, rated to 1,000 kg, with powered raise and lower and a deliberately low mast.
1,000 kg. The machine itself weighs 290 kg with the forks on.
From 90 mm at the bottom to 1,300 mm at the top, raised and lowered under power.
Yes, that is what the low mast is for. It can be wheeled through a window opening on a Liftroller Wall.
It is the same family of machine, but built for site rather than warehouse work. The short mast lets it get onto floors a taller warehouse stacker cannot reach.
110 V or 230 V.
Not covered here? Talk to our team and we will answer it against your actual site.
